CHAIN ​​THERMOFORMING PACKAGING MACHINE

PPM π-33 MIDI

  • Maximum Protector Protection
  • High Production Capacity
CHAIN ​​THERMOFORMING PACKAGING MACHINE

Product Information

Appropriate, effective and correctly designed packaging contributes to the protection and extension of the product's life, positively affects consumer trends and increases the sales of the product. The most accurate complement of a quality product is good packaging. Aware of this great responsibility, PİPAK promises health, quality and success to its valued customers by combining high quality with affordable prices thanks to its expert technical staff with an average of 20 years of experience in packaging machines and its flexible structure shaped according to customer demands.

Packaged Products

Cheddar Cheese
White Cheese
Olive
Salami
Sausages
Medical

Technical Specifications

Foil Materials
PVC / PE / APET / PE / PA / PE
Length
5,000 mm
Waste Winding
Machine Mounted
Foil Width
360 – 422 mm
Width
1,600 mm
Max.Foil Depth
90 mm
Height
2,000 mm
Capacity
6 – 8 cycle/min
Chassis Structure
AISI 304 Quality Stainless Steel
Air Pressure Requirement
6–7 Bar – 1200 l/min
Drive System
Electric and Pneumatic
Cooling Water Requirement
12–16 °C – 300 l/h
Traction System
Chain
Electricity Consumption
11 kW / h
Filling System
Pneumatic Time Controlled
Foil Feeding
Engine
Base
400 mm
Lid
250 mm

Product Video

PPM π-33 MIDI

High Capacity Storage

Increases productivity and improves the processing of products and containers by optimizing the timing of each work step.

Pick and Place

Increases efficiency by automating the insertion of pre-filled containers into the machine.

Absorption of Foreign Substances

It ensures product health by cleaning foreign objects at the bottom of the containers.

Ultra Cleaning System

UVC lamps offer disinfection options such as pulsed shock and nitrogen peroxide.

Filling Solutions

With the PİPAK π-11 Mini Max filling and sealing machine, you can fill all products, with or without pieces, from liquids to pastries such as yoghurt, fruit juice, white cheese, desserts, coffee creamer, baby food, cereals.
